Heavy Duty Drive-Over Fender Equipment/Car Hauler (14DF)
When you want to widen the scope of what you can haul, you need a trailer with a full-width, 102” deck in front and behind the fenders. That’s what the 14DF Heavy Duty Drive-Over Fender Equipment/Car Hauler offers, and then some. It features a Front Stop Rail, as well as D-Rings and Pockets for securing your gear, plus two 7,000-pound axles and a 36” cleated dovetail. As speaking of those fenders, they’re 3/16” diamond plated drive over fenders, looking good and standing strong, just like you as you go about your equipment hauling tasks.
Trailer Specifications
20' – 22''
Width
102"
Lengths
14,000 lbs
GVWR
10,325—10,660 lbs
Load Capacity
Features & Options
| Standard Feature | Click + for Options |
|---|---|
| Axles | 2 - 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs |
| Brakes | Forward Self-Adjusting Electric Brakes on Both Axles |
| Coupler |
2-5/16" Ball, Adjustable Demco EZ Latch Coupler|2-5/16" Round Gooseneck Coupler on Gooseneck models
Available Options |
| Safety Chains | 3/8" Grade 70 w/ Safety Latch Hook (2 ea) |
| Jack | 12,000# Drop-Leg Jack (Side Wind) |
| Frame | 6" Channel |
| Cross-Members | 3" Channel on 16" Centers |
| Front Stop Rail | 3/16" Fabricated Front Stop Rail (Bumper Pull Only) |
| Floor |
Treated Pine Floor
Available Options |
| Fenders | 3/16" Diamond Plate Drive Over Fenders |
| Ramps |
5' Rear Slide in Ramps w/ Stabilizer Jacks
Available Options |
| Dovetail | 3' Cleated Dovetail |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) |
| Trailer Plug | 7-Way RV |
| Lights | Recessed, Grommet-Mounted L.E.D. Lighting |
| Wiring | Sealed, Modular Cold-Weather Wiring Harness |
| Tires |
ST235/80 R-16 Load Range E Radial Tires
Available Options |
| Bolt Pattern | 8-Lug |
| Spare Mount | Front Spare Tire Mount |
| Spare Tire |
Not Included
Available Options |
| Paint Type | Professional Finish w/ Primer Standard |
| Paint Color |
Black
Available Options |
| Rubrail | Rub Rail Along Both Sides |
| Tie-Downs |
(6) 5/8" D-Rings
Available Options |
| Break-Away Kit | Complete Breakaway System w/ Zip Breakaway Cable |
Model Benefits
Effortless Maintenance
Forward, self-adjusting brakes make brake maintenance a breeze. The system automatically adjusts the brake shoes as they wear down, eliminating the need for manual adjustments.
Fast and Easy Hitching
The Demco EZ Latch Coupler is built to last and provides a fast and easy connection, and its automatic latching system securely locks when lowered—saving you both time and effort.
Get a Grip While You Load
Get a boost of confidence as you load in or out with our 36” cleated dovetail. It provides excellent traction and prevents slipping, keeping you moving through your task smoothly.
Diamond-Plate Drive-Over Fenders
These fenders live up to their tough look with a strong construction you can even drive on.
