Heavy Duty Over-The-Axle Tilt (14OT)
Bring your low-profile equipment hauling to new heights with the 14OT Heavy Duty Over-the-Axle Tilt Bed Equipment Trailer. It’s unlike any of our other trailers, highlighted by a scissor-style hydraulic hoist that offers stability, energy efficiency, and less maintenance than other systems. With a rear knife edge, a full 96”-wide tilt platform, and a winch mount plate at the front of the platform, you can take your productivity into overdrive with this over-the-axle workhorse.
Trailer Specifications
22' – 26''
Width
102"
Lengths
14,000 lbs
GVWR
8,710—9,255 lbs
Load Capacity
Features & Options
| Standard Feature | Click + for Options |
|---|---|
| Axles | 2 - 7,000# Premium, with Quick-Lubricating Hubs |
| Brakes | Forward Self-Adjusting Electric Brakes on Both Axles |
| Suspension | Multi-Leaf Slipper Spring w/ Equalizer |
| Coupler |
Adjustable 2-5/16” Demco EZ Latch, Round Adjustable Pin 2-5/16” on Gooseneck Model
Available Options |
| Safety Chains | 3/8" Grade 70 w/ Safety Latch Hook (2 ea) |
| Jack |
12,000# Drop-Leg Jack (Side Wind) Dual Jacks on Gooseneck Model
Available Options |
| Frame | 8" I-Beam, 10# / 13# on 26' Models |
| Cross-Members | 3" Channel |
| Front Stop Rail | 3/16" Fabricated Front Stop Rail (Bumper Pull Only) |
| Floor |
Treated Pine Floor
Available Options |
| Stake Pockets | Stake Pockets Along Both Sides (Quantity Varies by Length) |
| Trailer Plug | 7-Way RV |
| Lights | Recessed, Grommet-Mounted L.E.D. Lighting |
| Wiring | Sealed, Modular Cold-Weather Wiring Harness |
| Tires |
ST235/80 R-16 Load Range E Radial Tires
Available Options |
| Bolt Pattern | 8-Bolt |
| Spare Mount | Front Spare Tire Mount |
| Spare Tire |
Not Included
Available Options |
| Paint Type | Professional Finish w/ Primer Standard |
| Paint Color | Black |
| Tilt Deck Dimensions | 102" Wide with 1/4" Diamond plate Knife Edge |
| Tilt Deck Operation | Power Up/Power Down with Hydraulic System |
| Rubrail | Rub Rail Along Both Sides |
| Tie-Downs |
Available Options |
| Break-Away Kit | Complete Breakaway System w/ Zip™ Breakaway Cable and Charger |
| Power | Power Up/Power Down & Gravity Down Hydraulic Pump |
| Tilt Deck Angle | 16° |
| Winch Plate | Front Mounted Steel Winch Plate |
Model Benefits
Effortless Maintenance
Forward, self-adjusting brakes make brake maintenance a breeze. The system automatically adjusts the brake shoes as they wear down, eliminating the need for manual adjustments.
Hydraulic Scissor Lift System with Power Up/Power Down
An efficient and strong hydraulic lifting system that makes loading and unloading a simple task.
Rear Knife Edge with Collapsible Bumper
A knife edge at the rear makes loading and unloading easy and provides a smooth transition. The collapsible rear bumper also provides additional safety.
Front Mount Winch Plate Standard
Add an electric winch to the tilt platform with ease by using the standard equipped winch mount plate
